TheSingularityWorkshop.FSM_API 1.0.4

FSM_API

The blazing-fast, software-agnostic Finite State Machine system for any C# application.

Designed for flexibility. Built for robustness. Ready for anything.

🔍 Overview

FSM_API is a modular, runtime-safe, and fully event-aware Finite State Machine (FSM) system designed to plug directly into any C# application—from enterprise software to games, simulations, robotics, or reactive systems. It provides a powerful and decoupled approach to managing complex state-driven logic, ensuring clarity, consistency, and control across diverse domains.

✅ Thread-safe operations (main thread only, deferred mutation handling)

🧠 Decoupled state logic from data (POCO-friendly)

🏗️ Define once, instantiate many

🛠️ Error-tolerant FSM lifecycle management

🧪 Dynamic update ticking with frame/process throttling

No external dependencies. No frameworks required. No boilerplate setup. Pure C# power for your application's core logic.

💡 Why FSM_API?

Traditional FSM systems often suffer from tight coupling to specific environments or force rigid coding patterns. FSM_API liberates your state management: | Feature | FSM_API ✅ | Traditional FSM ❌ | |----------------------------------|------------|--------------------| | Framework agnostic | ✅ | ❌ | | Runtime-modifiable definitions | ✅ | ❌ | | Deferred mutation safety | ✅ | ❌ | | Named FSMs & Processing Groups | ✅ | ❌ | | Built-in diagnostics & thresholds| ✅ | ❌ | | Pure C# with no external deps | ✅ | ❌ |

🚀 Quickstart

1. Define a simple context (your data model): C#

public class LightSwitch : IStateContext
{
    public bool IsOn = false;
    public bool IsValid => true; // Essential for FSM validation
    public string Name { get; set; } = "KitchenLight";
}

2. Define and build your FSM: C#

// Optional: Create a named processing group for organizing FSM updates
FSM_API.CreateProcessingGroup("MainLoop");

var fsmDefinition = FSM_API.CreateFiniteStateMachine("LightSwitchFSM", processRate: 1, processingGroup: "MainLoop")
    .State("Off")
        .OnEnter(ctx => { if (ctx is LightSwitch l) l.IsOn = false; }) // Action when entering "Off" state
        .TransitionIf("On", ctx => ctx is LightSwitch l && l.IsOn) // Transition to "On" if IsOn is true
    .State("On")
        .OnEnter(ctx => { if (ctx is LightSwitch l) l.IsOn = true; }) // Action when entering "On" state
        .TransitionIf("Off", ctx => ctx is LightSwitch l && !l.IsOn) // Transition to "Off" if IsOn is false
    .BuildDefinition(); // Finalize the FSM definition

3. Create an instance for your context: C#

var kitchenLight = new LightSwitch();
// Associate your context with an FSM instance and assign it to a processing group
var handle = FSM_API.CreateInstance("LightSwitchFSM", kitchenLight, "MainLoop");

4. Tick the FSM from your application's main loop: C#

// Process all FSMs in the "MainLoop" group
FSM_API.Update("MainLoop");

🔧 Core Concepts

FSMBuilder: Fluently define states, transitions, and associated OnEnter/OnExit actions. This is your declarative interface for FSM construction.

FSMHandle: Represents a runtime instance of an FSM operating on a specific context. Provides full control over instance lifecycle, including pausing, resetting, and retrieving current state.

IStateContext: The interface your custom data models (Plain Old C# Objects - POCOs) must implement. This ensures clean separation of FSM logic from your application's data.

Processing Groups: Organize and control the update cycles of multiple FSM instances. Ideal for managing FSMs that need to tick together or at different rates (e.g., UI, AI, physics).

Error Handling: Built-in thresholds and diagnostics prevent runaway logic or invalid state contexts, ensuring application stability without crashing.

Thread-Safe by Design: All modifications to FSM definitions and instances are meticulously deferred and processed safely on the main thread post-update, eliminating common concurrency issues.

📦 Features at a Glance

📘 What’s Next?

📖 Full Documentation & Wiki (TBD)

🧪 Unit Tests & Benchmarks (Currently Under Development)

🔌 Plugins & Extension Framework (e.g., for visual editors, debugging tools)

🤝 Contributing

Contributions welcome! Whether you're integrating FSM_API into your enterprise application, designing new extensions, or just fixing typos, PRs and issues are appreciated.

📄 License

MIT License. Use it, hack it, build amazing things with it.

🧠 Brought to you by:

The Singularity Workshop — Tools for the curious, the bold, and the systemically inclined.

<img src="https://raw.githubusercontent.com/TrentBest/FSM_API/main/assets/TheSingularityWorkshop.jpg" alt="The Singularity Workshop" width="200" height="200">

Because state shouldn't be a mess.
