🧩 UMLGenerator

Chickensoft Badge Discord line coverage branch coverage

A tool for generating UML diagrams from C# code, designed to work seamlessly with Godot and .NET projects. UMLGenerator simplifies visualizing complex class hierarchies, and relationships through automated diagram creation.

<p align="center"> <img alt="Chickensoft.UMLGenerator" src="docs/icon.png" width="200"> </p>

📌 Overview

UMLGenerator produces PlantUML .puml files from your codebase, enabling easy visualization of:

  • Class inheritance trees
  • Component relationships
  • Method call dependencies

The generated diagrams are placed alongside source files with the *.g.puml extension, ready for rendering with PlantUML, VSCode extension, or the Jetbrains plugin.

🧰 Key Features

  • Automatic diagram generation from tscn and C# code
  • Integration with Godot.NET projects
  • Real-time visualization via IDE plugins

🧪 Example

using Chickensoft.UMLGenerator

public interface IGame
{
    void StartGame();
    void LoadGame();
    void SaveGame();
}

[GenerateUML]
public class Game : Node, IGame
{
	public IGameRepo GameRepo { get; set; } = null!;
	public IGameLogic GameLogic { get; set; } = null!;

    // ... (implementation details)
}

This would generate a PlantUML file showing:

  • Class relationships
  • Interface implementations
  • Method signatures

🖼️ Visualizing UML Diagrams

Generated .puml files can be visualized using PlantUML. For example:

classDiagram

  Game --> GameRepo
  Game --> GameLogic

  class Game {
      void StartGame()
      void LoadGame()
      void SaveGame()
  }

  class GameRepo {

  }

  class GameLogic {

  }

📚 Getting Started

  1. Install the UMLGenerator package
  2. Add <AdditionalFiles Include="**/*.tscn"/> so that all .tscn files within the project directory are found (may want to exclude addons)
  3. Add [GenerateUML] attribute to classes
  4. Build your project
  5. Open the generated .g.puml files
