WinFormedge 1.0.0

The WinFormedge Project

✨ About

WinFormedge is an open-source .NET library built on Microsoft WebView2, enabling developers to create modern, visually appealing WinForms applications using HTML, CSS, and JavaScript. With WinFormedge, you can seamlessly integrate web technologies into your WinForm projects, allowing for rich and interactive user interfaces.

🖥️ Requirements

Development Environment:

• Visual Studio 2022
• .NET 8.0 or higher

Deployment Environment:

• Windows 10 1903 or higher

This is a Windows ONLY library. It is not compatible with other operating systems.

The minimum supported operating system is Windows 10 version 1903 (May 2019 Update). And some fetures such as SystemBackdrop and SystemColorMode are only available on Windows 11.

🪄 Getting Started

Create a WinForm Application by using default project template

1. Replace initialization code by using WinFormedge application initialization procedure.

You should use FormedgeApp instead of Application class to initialize your WinForm application in the program.cs file. The FormedgeApp class is a builder for creating a WinFormedge application. It provides methods for configuring the application and running it.

using WinFormedge;

namespace MinimalExampleApp;

internal static class Program
{
    [STAThread]
    static void Main()
    {
        ApplicationConfiguration.Initialize();

        var app = FormedgeApp.CreateBuilder()
            .UseDevTools()
            .UseWinFormedgeApp<MyFormedgeApp>()
            .Build();

        app.Run();
    }
}

When the FormedgeApp class is created, it will automatically initialize the WebView2 environment and run the message loop.

2. Create a AppStartup class.

The AppStartup class is the entry point of your WinFormedge application. It provides methods for configuring the application. You can override the OnApplicationLaunched method to perform any initialization tasks before the application starts.

And you must override the OnApplicationStartup method to create the main window of your application. If the OnApplicationStartup method returns values created by StartupSettings class, the FormedgeApp class will create the main window of your application. Otherwise if the OnApplicationStartup method returns null the application will be closed.

using WinFormedge;

namespace MinimalExampleApp;

internal class MyFormedgeApp : AppStartup
{
    protected override AppCreationAction? OnApplicationStartup(StartupSettings options)
    {
        return options.UseMainWindow(new MyWindow());
    }
}

You can do some staffs like User Login, User Settings, etc. in the OnApplicationStartup method to determine using which window to start the application. Andalso you can end the application by returning null if conditions are not met.

3. Create a MainWindow class.

The MainWindow class is the main window of your application. It inherits from the Formedge class. You can use the Formedge class to create a window with a WebView2 control.

using WinFormedge;
using Microsoft.Web.WebView2.Core;

namespace MinimalExampleApp;
internal class MyWindow : Formedge
{
    public MyWindow()
    {
        Url = "https://embedded.appresource.local/";
        Size = new Size(1440, 900);
        AllowFullscreen = true;
        BackColor = Color.Transparent;

        // If you have embedded resources, you can set the virtual host name to access them.
        SetVirtualHostNameToEmbeddedResourcesMapping(new EmbeddedFileResourceOptions {
            Scheme="https",
            HostName="embedded.appresource.local",
            ResourceAssembly=Assembly.GetExecutingAssembly(),
            DefaultFolderName="Resources\\wwwroot"
        });

        Load += MyWindow_Load;
        DOMContentLoaded += MyWindow_DOMContentLoaded;
    }

    // Configure the window settings for the Formedge window.
    protected override WindowSettings ConfigureWindowSettings(HostWindowBuilder opts)
    {
        var win = opts.UseDefaultWindow();

        // Extends the content of the WebView into the non-client area of the window.
        win.ExtendsContentIntoTitleBar = true;
        // Sets the backdrop type of the window to blur behind or something else.
        win.SystemBackdropType = SystemBackdropType.BlurBehind;

        return win;
    }

    private void MyWindow_Load(object? sender, EventArgs e)
    {
        // Window and WebView2 are ready to use here.
    }

    private void MyWindow_DOMContentLoaded(object? sender, CoreWebView2DOMContentLoadedEventArgs e)
    {
        // The DOM content is loaded and ready to use here.
        ExecuteScriptAsync(""""
        (()=>{
            alert("Hello from WinFormedge!");
        })();
        """");
    }
}

Codes above creates a Formedge window. By using Url property, you can set the initial URL of the window. Sets the ExtendsContentIntoTitleBar property to true to extend the WebView into the non-client area of the window to create a borderless window. You can also set the Size property to set the initial size of the window.

The Load event is raised when the window and WebView2 are ready to use. You can use this event to perform any initialization tasks that require the WebView2 control to be ready.

The DOMContentLoaded event is raised when the DOM content is loaded and ready to use. You can use this event to perform any tasks that require the DOM content to be loaded.

4. Run the application.

You can run the application by pressing F5 in Visual Studio. The application will create a window with a WebView2 control that displays the Bing homepage.

You can drag the window by clicking and dragging the header element of the page and resize the window by dragging the edges of the window.
